SDL224-50 remote control mower with 50 L grass collector

SDL224-50 Remote Control Mower with Grass Collector

Compact tracked remote control mower with higher-power dual drive motors for slopes, orchards and vegetation management.

The SDL224-55B combines a 550 mm cutting width, 224 cc Loncin gasoline engine and dual 800 W electric track motors. Compared with the SDL224-55A, its higher drive-motor output and heavier tracked platform provide an alternative configuration for demanding terrain and vegetation management applications.

550 mm Cutting Width · 224 cc Engine · 800 W × 2 Drive · 175 kg

Mow & Collect in One Machine

Unlike standard remote control mowers that leave cut vegetation on the ground, the SDL224-50 features an integrated 50 L rear grass collector.

Four independent electric drive motors provide self-propelled movement, while wireless remote control allows the operator to control the machine from a distance.

Its 500 mm cutting width makes it particularly suitable for maintained green areas where maneuverability and grass collection are important.

Key Features

50 L Grass Collector
Collects grass during mowing for a cleaner finish and reduced post-mowing cleanup.
500 mm Cutting Width
Compact cutting width for lawns, gardens and landscaped areas.
224 cc Loncin Engine
Gasoline engine provides power for the mowing system.
350 W × 4 Electric Drive
Four electric drive motors provide four-wheel self-propelled movement.
Wireless Remote Control
Allows mowing and maneuvering from a distance.

Technical Specifications

Specification	Details	Specification	Details
Model	SDL224-50	Product Type	Remote Control Mower with Grass Collector
Cutting Width	500 mm	Deck Adjustment Range	0–180 mm
Travel Speed	0–5 km/h	Grass Collector Capacity	50 L
Operation	Wireless Remote Control	Drive System	Electric 4-Wheel Self-Propelled
Drive Motors	350 W × 4	Drive Voltage	24 V
Max. Remote Range	680 m*	Charging System	Engine Self-Charging
Generator Output	1,500 W	Fuel Tank Capacity	1.2 L
Engine Brand	Loncin	Engine Displacement	224 cc
Engine Type	Gasoline, Vertical Shaft, 4-Stroke	Starting System	Electric Start
Blade System	Parallel Swinging Blades	Machine Weight	158 kg
Machine Dimensions	1730 × 700 × 600 mm	Gross Weight	210 kg
Package Dimensions	1830 × 800 × 800 mm	Applications	Lawns, Gardens, Courtyards, Landscaping

* Manufacturer-stated maximum remote range. Actual range may vary depending on obstacles, interference and operating conditions.

Typical Applications

Lawns

Mowing and grass collection for maintained lawn areas.

Gardens

Compact 500 mm cutting width for residential and commercial garden maintenance.

Courtyards & Green Areas

Remote mowing where collection of grass clippings is preferred.

Landscaping

Suitable for routine maintenance of landscaped areas requiring a cleaner finish.

Find the Right Mower for Your Application

Need a mower for lawns, landscaping, slopes, orchards or heavier vegetation?

Tell us your terrain, vegetation type, working area and cutting requirements. MecBase can help you compare suitable remote control mower configurations.

SDL224-55A vs SDL224-55B

Specification	SDL224-50	SDL224-55A
Configuration	Wheeled + Collector	Tracked
Cutting Width	500 mm	550 mm
Engine	Loncin 224 cc	Loncin 224 cc
Drive Motors	350 W × 4	500 W × 2
Grass Collector	50 L	—
Travel Speed	0–5 km/h	0–3 km/h
Machine Weight	158 kg	131 kg
Primary Use	Lawns & Landscaping	Slopes & Uneven Terrain

SDL224-50 — Suitable when grass collection and a clean finish are priorities.

SDL224-55A — Suitable when a compact tracked configuration is required for slopes and uneven terrain.

How to Choose the Right Remote Control Mower

Before selecting the SDL196-50A or a larger tracked model, consider:

Terrain — lawn, uneven ground, slope or rough terrain?

Vegetation — maintained grass, weeds or dense vegetation?

Working slope — what angle will the machine normally work on?

Access width — does the machine need to pass through gates or narrow areas?

Cutting width — is maneuverability or mowing coverage more important?

Operating time — how many hours will the mower normally work?

For more demanding slopes, rough terrain or heavier vegetation, a tracked or heavier-duty mower configuration may be more appropriate.
